CJ series
Ergonomic multifunction joysticks
CONFIGURATION OPTIONS - continued
ADDITIONAL OUTPUT OPTIONS
CANbus J1939
CH Products CJ Series CANbus joysticks conform to the SAE J1939 serial bus specification used for communications
between electronic control units and vehicle components.
FEATURES
? CANbus J1939
? Extended I/O for up to 16 digital inputs (or a combination of digital inputs and a switch matrix) and eight analog
inputs.
? Accommodates a 6-40VDC power supply
ELECTRICAL SPECIFICATIONS
Supply Power:
Supply Current:
Red Wire
Black Wire
Green Wire
White Wire
Blue Wire
Orange Wire
- 6 – 40 VDC
- 15mA min, +5mA per LED, +6mA per axis
WIRING SPECIFICATION
- Supply Power
- Ground
- CAN high data
- CAN low data
- Identifier Select
- Identifier Select
CONNECTOR OPTIONS:
? Cable assembly with Deutsch DT04 style plugs
? External I/O harnessing per customer specification
CANbus CONFIGURATION CHART
? Contact factory for assistance
Note: The company reserves the right to change specifications without notice.
www.chproducts.com
